Sunday Blueprint 16" BMX (Gloss Blue)

Sunday Blueprint 16" BMX (Gloss Blue)

Regular price $559.99

Unit price per

only 0 left in stock

The Sunday Blueprint is a bike for new riders that is built around a pro-level geometry to help them progress faster.

This bike is equipped with hassle-free parts like Odyssey Springfield brakes, a Sunday Freeze stem and Current 2.4” tires to help keep you focused on the important part - riding. The Blueprint comes with an integrated head tube this year for greater durability, ease of assembly and pro style points.

Key Features

  • Sunday Current v2 2.4"
  • Odyssey Springfield Brakes
  • FSA Integrated Headset
  • Sunday Cornerstone Grips
  • Sunday Freeze Front Load Stem
  • KMC S1 Chain

Specifications

Frame: Sunday Blueprint, 20.5" top tube, integrated 1-1/8" head tube

Fork: Sunday Blueprint, 20" fork w/ 2-piece steerer tube and welded pre-load

Handlebar: Sunday, 2-piece

Stem: Sunday Freeze front load, 48mm

Headset: FSA integrated, 1-1/8"

Alloy Cap: FSA aluminum cap

Brake Lever: Aluminum, U-brake compatible

Brakes: Odyssey Springfield U-brake

Brake Cable: Odyssey Quik Slic

Grips: Sunday Cornerstone

Seat: Sunday Badge, seat and post combo

Seat Post: Integrated

Seat Clamp: Integrated

Sprocket: Sunday S-Logo, 25T, steel

Cranks: 160mm, 3-piece, chromoly

BB Parts: Loose-ball, American, 19mm

Pedals: Wellgo platform, plastic

Rims: P-7X aluminum, 20", 36H

Front Hub: Sunday, 36H, low-flange, loose-ball, 3/8" axle

Rear Hub: Sunday, 36H,14mm axle w/ 9t Driver

Spokes: 14g steel, black

Tires: Sunday Current, 20 x 2.4" (F & R)

Chain: KMC S1

Approx. Weight: 26lbs (with brakes)

Frame Geometry

Top Tube Length: 20.5"

Head Tube Angle: 75°

Seat Tube Angle: 71°

Chainstay Length: 13.2-13.5”

Bottom Bracket Height: 11.5"

Standover: 8.75"

Handlebar Geometry

Rise: 9"

Width: 28.5"

Backsweep: 12°

Upsweep:

    Please Note that all bike shipments are only partially assembled in box and will require some assembly feel free to contact us at Fufanu with any questions.
